HB120

HB120

Performance Characteristics The Hotbox series provide heating circulators with the functionality of the Pilot ONE controller for...
Vendor: Huber
SKU: 2043.0003.01
Availability: In Stock
Product Type: Circulation heaters
Dhs. 131,897.00 AED
Dhs. 131,897.00 AED
Subtotal: Dhs. 131,897.00
Terms & Conditions

Estimated Delivery 10-14 business day

Free Shipping

Free standard shipping on orders over 185 AED

Free Returns

Learn More ...

Authorized distributor

HB120

Huber

HB120

Dhs. 131,897.00
HB120

Huber

HB120

Dhs. 131,897.00
Products Specifications
Products Specifications
x

Temperature range 60...250 °C
Temperature stability ±0,1 K
Display resolution 0,01 K
Controller Pilot ONE
Safety class II / FL
Protection class IP20
Dimensions (W x D x H) 479 x 539 x 695 mm
Weight, net 88 kg

Heating capacity 10,5 - 12 kW

Delivery capacity pressure pump max. 100 l/min; 3,5 bar
Pump connection M30x1,5 AG male
Pump speed adjustable Yes
Pump type magnetically coupled, stainless steel
Pump characteristics Pressure pump, speed not variable

External sensor connection Pt100
Interface digital Ethernet, USB (Host u. Device), RS232

Permissible ambient temperature 5...40 °C
Power supply 380-460V 3~ 50/60Hz
Current consumption max. 20 A
Fuse 3x25A
Overview
Overview
x

Functions overview

  • High efficiency
  • Precise temperature control
  • Powerful circulation pump
  • Intelligent energy management
  • Reliable continuously operation with warning functions
  • Pilot ONE controller with 5.7" touchscreen
  • Digital filling level indicator
  • 2 x USB (Host and Device), Ethernet and RS232 interfaces
  • Compact construction; suitable for installation in plant

Product impressions

Controller

The multi-touch controller Pilot ONE offers a brilliant 5.7" touchscreen with graphic functions and a comfortable navigation menu. All important operating parameters and temperature values are neatly displayed on the touchscreen. Thanks to the new favourites menu, the one-click operation and the integrated technical glossary the operation is very easy, just like on a smartphone. Integrated USB and Ethernet ports allows connection to a PC or network, e.g. for remote control or data transmission.

Read more
Accessories
Accessories
x
Cursor
Temperature sensor Pt100, open, Ø 8 mm, 170 mm
Huber

Temperature sensor Pt100, open, Ø
8 mm, 170 mm

Sensor open in protective pipe Ø 8 mm (Pt100) with 1,5 m cable Sensor length: 170 mm, Ø 8 mm
Dhs. 4,488.00
Temperature sensor Pt100, closed, Ø 8 mm, 400 mm
Huber

Temperature sensor Pt100, closed, Ø
8 mm, 400 mm

with 1,5 m cable Sensor length: 400 mm, Ø 8 mm
Dhs. 3,628.00
Temperature sensor Pt100, closed, Ø 6 mm, 200 mm
Huber

Temperature sensor Pt100, closed, Ø
6 mm, 200 mm

with 1,5 m cable Sensor length: 200 mm, Ø 6 mm
Dhs. 3,460.00
Temperature sensor Pt100, closed, Ø 6 mm, 180 mm
Huber

Temperature sensor Pt100, closed, Ø
6 mm, 180 mm

with 1,5 m cable Sensor length: 180 mm, Ø 6 mm
Dhs. 3,146.00
Ball valve M30x1,5
Huber

Ball valve M30x1,5

Temperature range: -10...+180°C (max. 6 bar at + 180°C)
Dhs. 1,741.00
Drain valve, universal
Huber

Drain valve, universal

for all baths/thermostats connection screw G3/8" with sealing cap   (not suitable for polycarbonate baths 112A, 118A, 130A)
Dhs. 1,259.00
Connection cable for Pilot ONE
Huber

Connection cable for Pilot ONE

Connection cable for Pilot ONE for using the controller as remote control (without RS232) Length: 3m   Using #16160 as remote control does not allow communication via RS232. If required, please u...
Dhs. 881.00
Extension cable for temperature sensor
Huber

Extension cable for temperature sensor

with coupling and plug (Lemosa) Cable length: 3 m
Dhs. 2,244.00
Wall bracket Pilot ONE
Huber

Wall bracket Pilot ONE

Wall bracket for controller Pilot ONE and CC-Pilot
Dhs. 672.00
Table stand Pilot ONE
Huber

Table stand Pilot ONE

Table stand for controller Pilot ONE and CC-Pilot
Dhs. 1,594.00
Mounting bracket for wall mounting of Pilot ONE
Huber

Mounting bracket for wall mounting
of Pilot ONE

Mounting bracket for mounting the Pilot ONE wall bracket at the side of the device
Dhs. 588.00
Hose K-260-1-M30x1,5
Huber

Hose K-260-1-M30x1,5

Industrial plastic material hose with braiding Temperature range: -60°C...260°C Length: 100 cm Connection: M30x1,5 Max. pressure at 20°C: 6 bar Internal diameter: 20 mm Insulation: Special in...
Dhs. 5,578.00
Hose K-260-1,5-M30x1,5
Huber

Hose K-260-1,5-M30x1,5

Industrial plastic material hose with braiding Temperature range: -60°C...260°C Length: 150 cm Connection: M30x1,5 Max. pressure at 20°C: 6 bar Internal diameter: 20 mm Insulation: Special in...
Dhs. 6,711.00
Hose K-260-2-M30x1,5
Huber

Hose K-260-2-M30x1,5

Industrial plastic material hose with braiding Temperature range: -60°C...260°C Length: 200 cm Connection: M30x1,5 Max. pressure at 20°C: 6 bar Internal diameter: 20 mm Insulation: Special in...
Dhs. 7,759.00
Hose K-260-3-M30x1,5
Huber

Hose K-260-3-M30x1,5

Industrial plastic material hose with braiding Temperature range: -60°C...260°C Length: 300 cm Connection: M30x1,5 Max. pressure at 20°C: 6 bar Internal diameter: 20 mm Insulation: Special in...
Dhs. 10,108.00
Hose MT-350-1,5-M30x1,5
Huber

Hose MT-350-1,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 150 cm Nominal width: 20 mm Insulation: Special insulation with additional smooth silicone hose, ends covered with silicone caps.
Dhs. 7,675.00
Hose MT-350-1-M30x1,5
Huber

Hose MT-350-1-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 100 cm Connection: M30x1,5 Nominal width: 20 mm Insulation: Special insulation with additional smooth silicone hose, ends covered with s...
Dhs. 6,249.00
Hose MT-350-2-M30x1,5
Huber

Hose MT-350-2-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 200 cm Connection: M30x1,5 Nominal width: 20 mm Insulation: Special insulation with additional smooth silicone hose, ends covered with s...
Dhs. 8,850.00
Hose MT-350-3-M30x1,5
Huber

Hose MT-350-3-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 300 cm Connection: M30x1,5 Nominal width: 20 mm Insulation: Special insulation with additional smooth silicone hose, ends covered with s...
Dhs. 11,282.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
Hose MT-350-0,5-M30x1,5
Huber

Hose MT-350-0,5-M30x1,5

Material: Metal Temperature range: -100...350°C Length: 50 cm Connection: M30x1,5 Nominal width: 20 mm
Dhs. 5,830.00
