| Volume range (H2O) | 2 - 40 l |
| Stator diameter | 65 mm |
| Rotor diameter | 58 mm |
| Gap between rotor and stator | 0.5 mm |
| allowable Speed max. | 9500 rpm |
| Circumferential speed max. | 28.8 m/s |
| Immersion depth | 80 - 450 mm |
| Shaft length | 510 mm |
| Material in contact with medium | FFPM, WC /AISI 316L |
| pH range | 2 - 13 |
| Suitable for solvents | yes |
| Working temperature max. | 170 ðC |
| Sterilization methods | all methods |
| Vacuum | 1 mbar |
| Pressure max. | 6 bar |
| Ultimate fineness, suspensions | 20 - 50 õm |
| Ultimate fineness, emulsions | 5 - 15 õm |
| FDA conformity | yes |
| Dimensions (W x H x D) | 65 x 550 x 65 mm |
| Weight | 4.41 kg |
Data Sheet
Technical information S65KG-HH
