XA100 - Adapter for Pipettes calibration 100 ml XA 5Y

XA100 - Adapter for Pipettes calibration 100 ml XA 5Y

Vendor: Radwag
SKU: WX-001-0015
Availability: In Stock
Dhs. 6,826.00 AED
Dhs. 6,826.00 AED
Subtotal: Dhs. 6,826.00
Terms & Conditions

Estimated Delivery 10-14 business day

Free Shipping

Free standard shipping on orders over 185 AED

Free Returns

Learn More ...

Authorized distributor

XA100 - Adapter for Pipettes calibration 100 ml XA 5Y

Radwag

XA100 - Adapter for Pipettes calibration 100 ml XA 5Y

Dhs. 6,826.00
XA100 - Adapter for Pipettes calibration 100 ml XA 5Y

Radwag

XA100 - Adapter for Pipettes calibration 100 ml XA 5Y

Dhs. 6,826.00
Products Specifications
Products Specifications
x
Overview
Overview
x


XA100 - Adapter for Pipettes calibration 100 ml XA 5Y



XA100 pipette calibration adapter enables calibration and/or verification of piston pipettes by means of a gravimetric method using the XA analytical balence.

Set content:
  • base
  • weighing pan
  • weighing vessel
  • evaporation ring
  • glass chamber with an opening for dosing

Evaporation ring is an integral part of the adapter that increases relative humidity inside the weighing chamber. With this evaporation of the liquid during calibration/verification is stopped. An integrated weighing pan enables centric loading of the vessel in the weighing chamber. The weighing pan and the vessel are housed in a glass chamber featuring an opening allowing the user to dispense liquid through it, and reducing air drafts.

Vessel capacity: 100 ml

Adapters for Pipettes Calibration
Pipette calibration adapters are intended for calibration and verification of piston pipettes using gravimetric method. Use of the pipette calibration adapter reduces maximum capacity of the balance by the mass of the weighing vessel. The table below, which presents the minimum requirements in accordance with ISO 8655-6:2022 standard, enables to select suitable adapter for pipette calibration and respective balance version. The parameters of the balance have been selected so that the expanded uncertainty of measurement in use is less than ¼ of the maximum permissible error of the test object.


Nominal volume
of apparatus under test V

 Resolution
(d) mg		 Repeatability
(s)3mg		 Recommended balance
  Microbalances Analytical balances
0,5 µl ≤ V < 20 µl 0,001c 0,01d 0,006c, e 0,03d MYA 21.5Y
XA 6/21.5Y.M.A
XA 6/21.5Y.M
XA 21.5Y.M.A
XA 21.5Y.M
XA 21/52.5Y.M.A
XA 21/52.5Y.M
XA 53.5Y.M.A
XA 53.5Y.M

20 µl ≤ V < 200 µl 0,01 0,025 XA 52.5Y XA 110.5Y
XA 82/220.5Y.A
XA 82/220.5Y
XA 120/250.5Y.A
XA 120/250.5Y
200 µl ≤ V ≤ 10 ml 0,1 0,2
Adapter for pipette calibration  MY 11 XA 11 XA 11 XA 11 XA 11 XA 17 XA 17 XA 17 XA 100 XA 17 XA 100
Maximum vessel capacity  11 ml 11 ml 11 ml 11 ml 11 ml 17 ml 17 ml 17 ml 100 ml 17 ml 100 ml
Weighing vessel mass  ~ 10 g ~ 10 g ~ 10 g ~ 10 g ~ 10 g ~ 11 g ~ 11 g ~ 11 g ~ 65 g ~ 11 g ~ 65 g


a   The repeatability values, in this table, apply in the volumen determination of a single channel pipette. When a single-channel balance is used for volumen determination of single channel pipettes the repeatability values are double the values of this table.
c   Single-channel balance.
d   Multichannel balance, only valid for multi-channel pipettes. Multi-channel balances of 0,01 mg readability may be uses to test multi-channel pipettes with nominla volumes below 20 µl only if the expanded uncertainty in use is less than ¼ of the maximum permissible systematic error of the test object.
e   For single-channel pipettes of nominal volumes of less than 2 µl, a balance with repeatability better than the values in the table shall be used so that the expanded uncertainty in use is less than ¼ of the maximum permissible systematic error of the test object.
